High Speed Zipper Strip Hot Lamination Side Sealing Machine

分类: 封切机
国家: 台湾
电话: 886-6-5783420
传真: 886-6-5783347
联络人: 张总经理
马上询问
  1. The PLC controller is made in Taiwan and very stable.
  2. The size control of Zipper Bag Side Sealing Machine is by servo motor. Made in Japan.
  3. Zipper Bag Side Sealing Machine is equipped mark sensor for printed material.
  4. For getting the best quality of zipper bag product, unwinding station is mount the auto tension control.
  5. The individual zipper strip unwinder with motor control to get the high quality of zipper sealing quality.
  6. Ultrasonic welding is design by motor driven for highest speed production.
  7. The ultrasonic welding station to crack the zipper on the edge of the bag for easy side sealing cutting.
  8. the best design of zipper bag side sealing machine, made in Taiwan.
型式 MGA-06Z-700D
机械规格
占地面积 9,000 (L) × 1,480 (W) × 2,250 (H) mm
净重 4,060 kg
全台备电 16 kw
机械性能
使用原料 LDPE, HDPE, PP, EVA
单层膜厚度(Zipper Bag) a. Side sealing bag: 0.02 - 0.08 mm
b. zipper bag: 0.04 - 0.08 mm
有效袋长(Feeding Width) 85 - 600 mm
有效袋长(Sealing Width) 150 - 550 mm
产量 40 - 200 pcs /min (depend on size and thickness)
