医疗管押出整线设备
产品分类 : 管材与型材挤出生產线
Twinscrew 的醫療管材擠出機提供高精度和可靠性，適用於製造各種醫療管材。其機器涵蓋不同螺桿尺寸，能在擠出過程中實現嚴格的公差控制，適合生產醫療級管材。主要特點包括先進的真空冷卻系統、精確的雷射測量技術，以確保管材直徑的一致性，並可兼容多種材料如 PVC、TPU 和 PE。Twinscrew 的擠出生產線符合醫療標準，提供生產柔韌、耐用、安全的醫療管材的解決方案，適用於多種應用。
Vibrating Screen
产品分类 : 清洗与分选产线
The CYKF Vibrating Screen is used for sorting plastic pellets. It divides the pellets discharged from pelletizer. The machine can be combined with our strand pelletizing or underwater pelletizing extrusion lines.
Single Screw Underwater Pelletizing Extrusion Line | CK-S
产品分类 : 单螺杆挤出机
CYKF CK-S series Single Screw Underwater Pelletizing Extrusion Line can be applied to a wide range of applications. It is especially suitable for materials with high viscosity, low MI, and difficulty to be shaped, e.g., TPE and TPR. Possible materials : TPU, TPE, TPV, TPR, PP, PS, PLA, PVA, SEBS, EVA, Rubber, Hot-melt adhesive, Special resin, and Micro pellet, etc.
Co-rotating Twin Screw Underwater Pelletizing Compounding Line | CK-HT
产品分类 : 双螺杆挤出机
CK-HT series Co-rotating Twin Screw Underwater Pelletizing Compounding Extrusion Line is designed especially for compounding materials with high viscosity, low MI, or difficulty to be shaped. The extrusion line can be applied to a wide range of materials and applications. Possible materials: TPU, TPE, TPV, TPR, PP, PS, PLA, PVA, SEBS, EVA, Rubber, Hot-melt adhesive, Special resin, and Micro pellet, etc.
Co-rotating Twin Screw Strand Pelletizing Compounding Line | CK-HT
产品分类 : 双螺杆挤出机
CK-HT series Co-rotating Twin Screw Strand Pelletizing Compounding Extrusion Line is especially for composite materials that are suitable for strand pelletizing production method. It can be applied to a wide range of plastics. Possible materials: Various composite materials, e.g. PC, PE, PS, ABS, Nylon, LCP, PPS with additives of glass fiber, Wood powder, CaCO3.
Co-rotating Twin Screw Automatic Metering / Weighing / Conveying Pelletizing Compounding Line | CK-HT
产品分类 : 双螺杆挤出机
CYKF is committed to the R&D and manufacturing of the automatic extrusion systems, and constantly strives for perfection. The CK-HT series Co-rotating Twin Screw Automatic Metering Weighing and Conveying Pelletizing Compounding Extrusion Line successfully overcomes the problem of customer limited site space and configures the optimal traffic line for customers. The high-efficiency system shows the advantages of safety, convenience, efficiency and quality, reflecting the greatest value of CYKF.
THREE LAYER BLOWN FILM EXTRUDER PLASTIC INFLATION MACHINE : KMTL-E3
产品分类 : 吹膜挤出机
The KMTL-E3 is a three-layer HDPE/LDPE/LLDPE/mLDPE blown film extrusion line offered in three sizes, with film widths from 900 to 1,800 mm and thickness from 0.02 to 0.20 mm, suited to car film, food packaging, and courier bags.The line comprises the KMTL-40-45-40 E3, KMTL-45-55-45 E3, and KMTL-55-65-55 E3 configurations, with screw diameters of Ø 40-45-40 mm, Ø 45-55-45 mm, and Ø 55-65-55 mm (28:1 L/D ratio), driven by 15-20-15 HP, 20-30-20 HP, and 30-50-30 HP AC motors with inverter. Film output ranges from 110 to 250 kgs/hr across the three sizes.Model line: KMTL-40-45-40 E3 / KMTL-45-55-45 E3 / KMTL-55-65-55 E3Suitable material: HDPE/LDPE/LLDPE/mLDPEFilm thickness: 0.02-0.15 mm / 0.025-0.20 mm / 0.03-0.20 mmFilm width range: 900 mm / 1400 mm / 1800 mmFilm output: 110 kgs/hr / 150 kgs/hr / 250 kgs/hrScrew diameter/type: Ø 40-45-40 mm / Ø 45-55-45 mm / Ø 55-65-55 mm, L/D ratio 28:1Driving motor: AC 15-20-15 HP / 20-30-20 HP / 30-50-30 HP + InverterDie diameter: Ø200 mm / Ø300 mm / Ø500 mmTake-up speed: 65 m/min / 45 m/min / 40 m/min
Side Force Feeder Type Double Section Recycling Pelletizing Extrusion Line | CK-SFD
产品分类 : 塑料制粒和配料生产线
CK-SFD series Side Force Feeder Type Plastic Recycling Pelletizing Line is ideal for recycling dirty plastic crushed films. Possible materials : EPE, EPP, EPS, PP, HDPE, LDPE, ABS, PS crushed films or flakes.
Side Force Feeder Type Recycling Pelletizing Extrusion Line | CK-SF
产品分类 : 塑料制粒和配料生产线
CK-SF series Side Force Feeder Type Plastic Recycling Pelletizing Line is ideal for recycling clean or washed plastic crushed films. Possible materials : EPE, EPP, EPS, PP, HDPE, LDPE, ABS, PS crushed films.
Co-Extrusion Two Layer HIPS/GPPS Sheet Extrusion Machine
产品分类 : 薄膜和片材挤出生产线
Co-Extrusion Two Layer HIPS/GPPS Sheet Extrusion Machine
板材押出生产线
产品分类 : 薄膜和片材挤出生产线
单层和多层板材生产系统的最多达5层 灵活可靠的下游设备 完整的板材押出生产线含55-200mm的押出机 加工能力：ABS, PE, PP, PS, PET, PC, PMMA, 和其他热塑性材料
PP板材押出生产线
产品分类 : 薄膜和片材挤出生产线
Mono layer & Multi-layer Sheet Extrusion Systems for up to 5 layers. Versatile & reliable downstream equipment.Complete Sheet Extrusion Line with extruders from 55-250mm. Processing Capabilities: ABS, PE, PP, HI/PS, PET, PC, PMMA and other thermoplastic materials.
2400mm PP / PC中空板材押出生产线
产品分类 : 薄膜和片材挤出生产线
For 47 years, Chi Chang has been designed and manufacturing fully computerised lines for sheet & film extrusion and co-extrusion. Our highly qualified team of engineers, operators and technicans has always been searching for high extrusion technology to meet your requirements. After years reserching since our first PP hollow profile sheet extrusion line in 1987, our new generation will produce PP hollow profile sheet with width from 1200mm to 2500mm, thickness from 2mm to 10mm and output upto 500 kg/hr. In the mean time, we are pleased to introduce our new PC hollow profile sheet extrusion line. It is able to produce two-layer and three-layer PC hollow profile sheet with width 1200mm & 2100mm and thickness 5mm-10mm (two-layer) and 16mm (three-layer), and output upto 500 kg/hr.
Side Shredding Type Recycling Pelletizing Extrusion Line | CK-SC
产品分类 : 塑料制粒和配料生产线
CK-SC series Side Shredding Type Plastic Recycling Pelletizing Line is ideal for recycling clean or washed plastic film, fiber, carpet, fabric, jumbo bag, etc. Possible materials : PP, HDPE, LDPE, PET, PC film, Nylon fiber, PP carpet, Jumbo bag, EPE, EPP, EPS, etc.
PVC Pelletizing Extrusion Line | CK-DT
产品分类 : 双螺杆挤出机
CYKF is well-known in PVC extrusion. Our CK-DT series Counter-rotating Twin Screw Extruder is especially designed for PVC. The available screw diameter is between 55 to 130mm. We never stop improving our PVC extrusion technology and we love sharing ideas with customers. Our in-depth understanding of PVC enables us to design better extrusion lines compared to other competitors. CYKF’s PVC extruder is high-efficient and durable, its outstanding performances has earned highly praises from global users.
