电晕表面处理机 - T型/吹膜机用
产品分类 : 吹膜挤出机
电晕处理机是一种表面改性技术，用于改善附着力处理。 它使用低温电晕放电等离子体来改变表面的特性。 塑料、薄膜、铝泊、铜泊、电镀膜(镀铝膜)、布料(纺织品)或纸张等材料可以通过电晕等离子体，以改变材料的表面能。 所有材料都具有固有的表面能。 表面处理系统几乎适用于任何表面形式，包括3D立体物体、片材和卷材。 电晕处理是塑料薄膜、挤出和印刷加工行业广泛使用的表面处理方法。 又称塑料表面处理机、塑料表面处理机、表面电晕处理机、大气等离子、大电电浆、电晕放电处理、静电处理机、塑料表面放电处理设备、电晕处理机、电晕处理装置、放电机、电火花机。 应用 挤出/押出: ．吹膜机 / 吹袋机 / ABA共挤 / Inflation machine ．流延膜/片材挤出/挤出涂层/涂层层压/挤出层压/淋膜机 印刷: ．联机印刷机/凸版印刷机/柔版印刷机/凹版印刷机/编织袋印刷/标签印刷/溶剂印刷/水性印刷/背对袋印刷 复合与加工 ．分切复卷机/涂布/湿式贴合/干式贴合/热贴合/无溶剂贴合/分条机/复合机/涂胶机 机型 CH-800S / CH-1000S / CH-1200S / CH-1500S / CH-2000S / CH-3000S / CH-5000S CH-800T / CH-1000T / CH-1200T / CH-1500T / CH-2000T / CH-2KT CH-3000T / CH-5000T / CH-8000T CH-3KT / CH-5KT / CH-8KT / CH-10KT / CH-12KT / CH-15KT / CH-20KT CH-3KD / CH-5KD / CH-8KD / CH-10KD / CH-12KD / CH-15KD / CH-20KD 适用材料 HDPE, LDPE, LLDPE, MLLDPE, PET, PVC, PP, OPP, CPP, BOPP, PI, PS, PC, EVA, Nylon, PTFE, PU, TPO, TPE, TPO PE woven, PP woven, 编织袋，编织布 Metalized film, FPC, Foil, 铝泊, 铜泊 Non woven, Melt blown, Fabric, textile, 无纺布, 不织布, 熔喷布
LDPE双模头夹链吹机
产品分类 : 吹膜挤出机
夹链胶膜系统 - 夹链与胶膜同时押出。可以配置整线生产(押出机-印刷机-制袋机)。 双袋系统 - 小袋与2个夹链押出，并在制袋机上冷边剖。 双模具系统 - 单螺杆押出，2个押出模头。
Zipper Bag Blown Film Machine
产品分类 : 吹膜挤出机
Designed to produce single line & double lines zipper bags, double zipper bags are upto the bags size & die. Different range film length should match different die & cooling ring Color injection extruder is an option.
TWO LAYER HDPE/LDPE/ LLDPE HIGH SPEED PLASTIC INFLATION MACHINE : KMTL-55
产品分类 : 吹膜挤出机
The KMTL-55 is a two-layer HDPE/LDPE/LLDPE high-speed plastic inflation (blown film extrusion) machine, producing two-layer PE film at widths up to 1,400 mm for applications such as car film and food plastic wrap.The extruder is built around a Ø 55mm x 2 screw with a 28:1 L/D ratio and a 30 HP AC driving motor with inverter. The die unit uses a Ø350 mm die and Ø400 mm air ring. Film thickness ranges from 0.025 to 0.15 mm, output reaches 20-150 kgs/hr, and the take-up unit runs at speeds up to 45 m/min.Model: KMTL-55Suitable material: HDPE/LDPE/LLDPEFilm thickness: 0.025-0.15 mmFilm width range: 1400 mmFilm output: 20-150 kgs/hrScrew diameter/type: Ø 55mm x 2, L/D ratio 28:1Driving motor: AC 30 HP + InverterDie diameter: Ø350 mm / Air ring diameter: Ø400 mmMachine dimension: 500x500x800 cm
TWO LAYER HDPE/LDPE/ LLDPE HIGH SPEED PLASTIC INFLATION MACHINE : KMTL-40/45
产品分类 : 吹膜挤出机
The KMTL-40/45 is a two-layer high-speed plastic inflation machine for blown film extrusion of HDPE, LDPE, and LLDPE resins, producing 2-layer PE film up to 800 mm (KMTL-40) or 900 mm (KMTL-45) wide for applications such as car film and food plastic wrap.The KMTL-40 runs twin Ø40mm screws with a 20 HP AC driving motor and 6-zone auto thermo control, producing film at 15-70 kgs/hr; the KMTL-45 runs twin Ø45mm screws with the same 20 HP AC driving motor and 2-zone auto thermo control, producing film at 20-90 kgs/hr. Both models operate at a 26:1 L/D ratio and a take-up speed of 70 m/min.Models: KMTL-40 / KMTL-45Suitable material: HDPE/LDPE/LLDPE (both)Film thickness: 0.010-0.15 mm (both)Film width range: KMTL-40 800 mm; KMTL-45 900 mmFilm output: KMTL-40 15-70 kgs/hr; KMTL-45 20-90 kgs/hrScrew diameter/type: KMTL-40 Ø40mm x2; KMTL-45 Ø45mm x2 (L/D ratio 26:1 both)Driving motor: AC 20 HP + Inverter (both)Take-up speed: 70 m/min (both)Machine dimension: KMTL-40 450×200×400 cm; KMTL-45 470×220×450 cm
TWO LAYER HDPE/LDPE/ LLDPE HIGH SPEED PLASTIC INFLATION MACHINE : KMTL-65
产品分类 : 吹膜挤出机
The KMTL-65 is a two-layer HDPE/LDPE/LLDPE high-speed plastic inflation (blown film extrusion) machine, producing two-layer PE film at widths up to 2,000 mm for applications such as car film and food plastic wrap.The extruder uses a Ø 65mm x 2 screw with a 28:1 L/D ratio and a 50 HP AC driving motor with inverter. The die unit is fitted with a Ø500 mm die and Ø550 mm air ring. Film thickness ranges from 0.03 to 0.15 mm, output reaches 60-250 kgs/hr, and the take-up unit runs at speeds up to 40 m/min.Model: KMTL-65Suitable material: HDPE/LDPE/LLDPEFilm thickness: 0.03-0.15 mmFilm width range: 2000 mmFilm output: 60-250 kgs/hrScrew diameter/type: Ø 65mm x 2, L/D ratio 28:1Driving motor: AC 50 HP + InverterDie diameter: Ø500 mm / Air ring diameter: Ø550 mmTake-up speed: 40 m/min
TWIN HEAD HDPE PLASTIC INFLATION MACHINE : KMH-45T
产品分类 : 吹膜挤出机
The KMH-45T is a twin head HDPE plastic inflation machine producing double output HDPE film, with combined yield up to 48 kg/hour, width up to 400 mm per head, and thickness between 0.008 and 0.06 mm.Each head runs a Ø45 mm screw with a 28:1 L/D ratio and 9.6 kw heating capacity, cooled by a 1/8 HP x 3 barrel cooling fan and driven by a 20 HP AC motor with inverter. The die unit (2 units) uses Ø50 mm dies with Ø100 mm air rings and a 3 HP cooling blower, and the take-up unit runs at speeds up to 85 m/min.Model: KMH-45TSuitable material: HDPEFilm thickness: 0.008 ~ 0.06 mmFilm width range: 400 mm × 2Film output: 24 kgs/hr × 2Screw diameter/type: Ø45 mm x 2, L/D ratio 28:1Driving motor: AC 20 HP + InverterDie diameter: Ø50 mm x 2 / Air ring diameter: Ø100 mm x 2Take-up speed: 85 m/min
TWIN HEAD(A/B/A LAYER) HDPE / LDPE / LLDPE PLASTIC INFLATION MACHINE : KMTL-4545T
产品分类 : 吹膜挤出机
The KMTL-4545T is a twin head (A/B/A layer) HDPE/LDPE/LLDPE plastic inflation machine that produces double output film at widths up to 400 mm per head, for applications such as car film and food plastic wrap.Each head runs a Ø 45mm screw with a 28:1 L/D ratio, driven by a 20 HP AC motor with inverter. The ABA die unit uses Ø60/80 mm dies with a Ø120 mm air ring per head. Film thickness ranges from 0.010 to 0.10 mm, output reaches 10-32 kgs/hr per head, and the take-up unit runs at speeds up to 85 m/min.Model: KMTL-4545TSuitable material: HDPE/LDPE/LLDPEFilm thickness: 0.010-0.10 mmFilm width range: 400 mm x 2Film output: 10-32 kgs/hr x 2Screw diameter/type: Ø 45mm x 2, L/D ratio 28:1Driving motor: AC 20 HP + InverterDie diameter (ABA): Ø60/80 mm x 2 / Air ring diameter: Ø120 mm x 2Take-up speed: 85 m/min
