Hot Stamping Machine THS-1020

The machine base and printing slide sleeve are made from sand-cast components combined with solid aluminum stock and sheet-metal steel processing. Precision linear guide rods form the basis of the internal motion structure.

The entire machine uses servo motors for forward/backward slide movement and up/down print-head movement, with direct screw drive.

The HMI uses text descriptions designed for intuitive operation.

The heating module places heating plates or tubes inside an aluminum guide block, with temperature set through a digital display.

In addition to manual foil placement, the machine includes a roll-feed mechanism. After the foil reaches the preset photoelectric positioning point, it automatically descends onto the workpiece; the feed distance can be set as required.

The hot-stamping pad can be adjusted manually and independently in the forward/backward and left/right directions. The fixture table height can also be adjusted manually.

A safety structure can be added according to customer requirements.
