型号 | 国际规格 | 射出压力 | 理论射出容积 | 四柱内距 | 开模行程 |
CX-60 | 600H-167 | 97 | 60 | 330x330 | 320 |
CX-100 | 1000H-387 | 226 | 100 | 380x380 | 370 |
CX-130 | 1300H-517 | 318 | 130 | 430x430 | 410 |
CX-160 | 1600H-764 | 442 | 160 | 500x500 | 490 |
CX-200 | 2000H-1078 | 594 | 200 | 560x560 | 550 |
CX-250 | 2500H-1400 | 778 | 250 | 610x610 | 600 |
CX-300 | 3000H-1727 | 995 | 300 | 680x680 | 660 |
CX-350 | 3500H-2101 | 1251 | 350 | 730x730 | 710 |
CX-450 | 4500H-3079 | 1885 | 450 | 810x810 | 780 |
CX-550 | 5500H-4316 | 2704 | 550 | 880x880 | 860 |
CX-700 | 7000H-5437 | 3261 | 700 | 960x960 | 950 |
CX-950 | 9500H-8472 | 4752 | 950 | 1160x1160 | 1250 |
CX-1250 | 12500H-12672 | 7433 | 1250 | 1360x1360 | 1500 |
CX-1600 | 16000H-16810 | 11486 | 1600 | 1560x1460 | 1700 |
STRUCTURAL REINFORCED PLATENS DESIGN
The movable platen has a box-shaped design with a T slot and a tapped mounting layout; the thickness and rigidity of the platen are both strengthened to minimize its deformation. A self-lubricated compound plate is supported at the bottom to reduce the friction of the plate with the steel tape. The layout of the platen mounting follows Euromap standards. Optional features such as the installation of a proportional valve for positional control or an ejector on the fly are also available.
