PLA挤出片材挤出机

分类: 单层/多层板材机

国家:

电话: 886-6-2532157

传真: 886-6-2533079

联络人: 魏淑珍小姐

Resin	PLA
Product thickness	0.2-1.2 mm
Product width	350 mm(MIN.)-600 mm (MAX.)
Capacity	120-150 kg/hr
Mechanical speed(Max)	Before stretch: 1.0-10 m/min; after stretch: 60 m/min
Extruder	75mm dia. L/D=32:1
Main power	75 HP A.C. inverter motor
Screen changer	hydraulic pump
T-die	FKI made
Die lip	up to 2 mm thick for product
Polishing roller unit	vertical type
Polishing roller	φ 350 M/M dia. x 900 M/M x 3
Motor	3 HP A.C. inverter for middle roller 2 HP A.C. inverter for upper & lower roller
Line speed	1.0 – 10.0 m/min
Winding dia	φ 600 mm (MAX.)
Electric cabinet	1 set
