HBA Series Continuous Extrusion Blow Moulding Machine

分类: 连续式塑胶中空成型机/多层中空成型机
国家:
电话: 886-6-2532157
传真: 886-6-2533079
联络人: 魏淑珍小姐
马上询问

High Efficiency and Eco-Friendly Design

The FKI All-Electric HDPE Bottle Making Machine is specifically engineered for producing 200ml and 500ml shampoo bottles from HDPE (High-Density Polyethylene) material. This advanced machine integrates an energy-saving system, drastically reducing power consumption while maintaining high-speed, consistent output. With its fully electric operation, the machine eliminates the need for hydraulic oil, ensuring a cleaner, more sustainable manufacturing environment.

All Electric Blow Moulding Machine
Quad Head, Double Station
For 200ml, 500ml shampoo bottle

  • Precision Control: Equipped with a state-of-the-art servo motor system, this HDPE bottle making machine delivers precise control over the blow moulding process, ensuring uniform quality for every bottle.
  • Energy Efficiency: The all-electric design results in up to 30% energy savings compared to conventional hydraulic machines, making it an ideal choice for eco-conscious manufacturers.
  • Compact Design: Its space-saving structure makes it perfect for factories with limited room, all while maintaining excellent production capacity.
  • Smart Manufacturing Ready: Fully integrated with Industry 4.0 capabilities, enabling real-time data monitoring and process optimization, maximizing efficiency and minimizing downtime.

Ideal for producing HDPE bottles for shampoo, this machine is also versatile enough for other personal care products such as conditioner and body wash bottles. It is particularly suited for manufacturers looking for efficient, high-quality HDPE bottle production.



塑料

HDPE 5502 grade

产品

500~700ml
NET 38g、Gross 52g

产能

2400pcs/hr

押出机马力

CMG 37kW gear reducer motor +AB vector inverter control (75HP)

押出机螺杆

φ65mm,L/D=30,barrier flight design with MADDOCK mixing zone

押出量

150kg/hr(max.)

模头设计

HDPE Four Head,Torpedo design with double spider support leg

膜嘴尺寸

φ62mm (max.)

油液压马达

multi-connecting rod with self-lock

夹模板( H x W ) 300x600mm(HxW)
夹模力 Design 140kN(14tons),Operate 100kN(10tons
夹模距离 280~425mm,fixed
模具厚度 280mm,fixed
移模行程 630mm(max.650mm)
压力值
冷却系统 NA
除胚装置
